SW Micro Welder – P300 (with an LCD monitor)          SW Micro Welder – P300 (used in production line)



· Patented machine for welding Φ 0.02-0.20 mm enameled wires or metal wires

· Adjustable, accurate and stable weld force

· Making small, precise and consistent welds

· High efficiency, exceptional performance and long service life



The 2012 New-type SW Micro Welder is more precise and intelligent than previous types by its new components to achieve higher-quality weldings:

>> Precise Electrode Force System -- controls and adjusts welding electric current intelligently

>> Automatic Brake -- stops over force from burning the workpiece

>> Weld Quality Monitoring Device -- monitors the welding process in real time

>> Set-Top Box -- stores welding data automatically in computers or portable devices during the process

>> HD LCD Monitor and Stereo Microscope -- shows clear and real-time images of the welding, seamlessly switchable between each other



Input Power	220V, 50HZ, 180VA(220V±5V); 110V, 60HZ, 180VA(115V±5V)
Max. Weld Power	300A
Frequency	120 times per minute
Weld Force	0.1–2.9 N
Size of Welded Wire	Φ 0.02-0.20 mm



SW Micro Welder – P300 (with an LCD monitor)



SW Micro Welder – P300 (used in production line)



* See Accessories

* All descriptions are subject to the actual product. Please contact us for any updates.
